CAD GXL2200
Offering exceptional versatility, the GXL2200BP is a large diaphragm condenser microphone fi nished in lustrous black pearl chrome. The GXL2200BP’s capsule features a sophisticated 1″ gold-vapor deposited diaphragm. Exceptional sensitivity and low distortion make it an outstanding performer in a variety of live and recording applications. Shock mount, vinyl pouch and polishing cloth included.
Operating Principle ………. Externally-Biased Condenser
Polar Pattern ………………………………………………. Cardioid
Frequency Response …………………………….30Hz -20KHz
Sensitivity ………………………………-36dBV (16mV) @ 1 Pa
Impedance ………………………………………………… 75 ohms
Max SPL ……………………………………………………….. 130dB
Self Noise ……………………………………………………. 20dBA
Dimensions …………………………………………(see drawing)
High-Pass ………………………………………….100Hz, 6dB/oct
Power Requirements ……………………………….. P48, 3mA
Weight ………………………………………………..14oz [0.40Kg]
RoHS ………………………………………………………. Compliant
